Technical details
| Series | 41 DB |
| Set-up | 1'D1' (2-8-2) |
| Length | 23905 mm |
| Diameter driving wheels | 1600 mm |
| Weight full | 102 ton |
| Weight empty | 93 ton |
| Overheated area | 96 m2 |
| Grate area | 4 m2 |
| Gear | Heusinger |
| Cilinders | 2: 520x720 mm |
| Fuel capacity | coal: 10 ton |
| Water capacity | 34 m3 |
| Power | 1427 kW |
| Remarks | Originaly standard class 41 of the DRG, was fitted with a new boiler by the DB. |
