Story
Technical details
| Series | LBE G8.2 |
| Set-up | 1'D (2-8-0) |
| Length | 18645 mm |
| Diameter driving wheels | 1400 mm |
| Weight full | 114 ton |
| Overheated area | 52 m2 |
| Grate area | 3 m2 |
| Gear | Heusinger |
| Cilinders | 2: 620x660 mm |
| Fuel capacity | coal: 3 ton |
| Water capacity | 16 m3 |
| Power | 1022 kW |
| Remarks | These engines were based on the Pruisian G8.2, however a bit longer and - thanks to changed gears and brakes - quicker. |
